Category: Extension Cables

Have a cable or pig tail that isn’t quite long enough? Does your LCD panel have a data cable built in that does't quite reach the driver board? Did your backlight come with a pigtail with only a few inches of wire? We may have the part you are looking for already available. If not, we can design a custom extension to fit your needs.

Contact us to learn how we can assist you with your cable needs. At Quadrangle our Engineers are also our Sales team. You will work directly with our Application Engineers who will guide you through the entire cable process including your custom quote. We believe this helps to provide a superior customer experience from concept to turnkey solution.

Confused? Don't be! More often than not our customers are unfamiliar with the process of acquiring a cable. Our Engineering/Sales support is FREE of charge! We make it as easy as possible to assist you with the design and requirements of your request. Starting with our custom quote, throughout the purchase, and with our continual support over the life of our products, we are sure we will be an asset to you and your company. We consider it our goal to take out most of the guess work providing a simple process resulting in a turnkey product we assure you will be satisfied with.

Extension Cables

Item Code Image Description Pitch (mm) Conductors Orientation Plating Length (in) Length (mm) File
800-00167

QD23204-15:    15" EXTENSION for 0.50mm 33 position
This kit allows you to extend 0.50mm pitch 33 position FFC/FPC cables by 15".  It consists of
our QD7018-33C adapter board that allows two FFC/FPC parts to be connected together, along with our stock 33 position 0.50mm pitch 15" long FFC.

 0.50 33
800-00166

QD23206-15:  15" EXTENSION for 0.50mm 45 position
This kit allows you to extend 0.50mm pitch 45 position FFC/FPC cables by 15". It consists of our QD7018-45C adapter board that allows two FFC/FPC parts to be connected together, along with our stock 45 position 0.50mm pitch 15" long FFC.

 0.50 45 15
800-00165

QD23201-5:    5" EXTENSION for 0.50mm 10 position
This kit allows you to extend 0.50mm pitch 10 position FFC/FPC cables by 5".  It consists of our QD7018-10C adapter board that allows two FFC/FPC parts to be connected together, along with our stock 10 position 0.50mm pitch 5" long FFC.

 0.50 10
800-00164

QD23205-9:  9" EXTENSION for 0.50mm 40 position
This kit allows you to extend 0.50mm pitch 40 position FFC/FPC cables by 9". It consists of our QD7018-40C adapter board that allows two FFC/FPC parts to be connected together, along with our stock 40 position 0.50mm pitch 9" long FFC.

 9
800-00155

QD23202-12:    12" EXTENSION for 0.50mm 20 position
This kit allows you to extend 0.50mm pitch 20 position FFC/FPC cables by 12".  It consists of our QD7018-20C adapter board that allows two FFC/FPC parts to be connected together, along with our stock 20 position 0.50mm pitch 12" long FFC.

 0.50 20 12
800-00154

QD23202-9:    9" EXTENSION for 0.50mm 20 position
This kit allows you to extend 0.50mm pitch 20 position FFC/FPC cables by 9".  It consists of our QD7018-20C adapter board that allows two FFC/FPC parts to be connected together, along with our stock 20 position 0.50mm pitch 9" long FFC.

 0.50 20 9
800-00153

QD23202-6:    6" EXTENSION for 0.50mm 20 position
This kit allows you to extend 0.50mm pitch 20 position FFC/FPC cables by 6".  It consists of our QD7018-20C adapter board that allows two FFC/FPC parts to be connected together, along with our stock 20 position 0.50mm pitch 6" long FFC.

 0.50 20 6
800-00152

QD23202-3:    3" EXTENSION for 0.50mm 20 position
This kit allows you to extend 0.50mm pitch 20 position FFC/FPC cables by 3".  It consists of our QD7018-20C adapter board that allows two FFC/FPC parts to be connected together, along with our stock 20 position 0.50mm pitch 3" long FFC.

 0.50 20 3
800-00151

QD23201-3:    3" EXTENSION for 0.50mm 10 position
This kit allows you to extend 0.50mm pitch 10 position FFC/FPC cables by 3".  It consists of our QD7018-10C adapter board that allows two FFC/FPC parts to be connected together, along with our stock 10 position 0.50mm pitch 3" long FFC.

 0.50 10 3
800-00150

QD23203-7:    7" EXTENSION for 0.50mm 30 position
This kit allows you to extend 0.50mm pitch 30 position FFC/FPC cables by 7".  It consists of our QD7018-30C adapter board that allows two FFC/FPC parts to be connected together, along with our stock 30 position 0.50mm pitch 7" long FFC.

 0.50 30 7
800-00149

QD23203-3:    3" EXTENSION for 0.50mm 30 position
This kit allows you to extend 0.50mm pitch 30 position FFC/FPC cables by 3".  It consists of our QD7018-30C adapter board that allows two FFC/FPC parts to be connected together, along with our stock 30 position 0.50mm pitch 3" long FFC.

 0.50 30 3
800-00148

QD23203-2:    2" EXTENSION for 0.50mm 30 position
This kit allows you to extend 0.50mm pitch 30 position FFC/FPC cables by 2".  It consists of our QD7018-30C adapter board that allows two FFC/FPC parts to be connected together, along with our stock 30 position 0.50mm pitch 2" long FFC.

 0.50 30 2
800-00147

QD23206-9:  9" EXTENSION for 0.50mm 45 position
This kit allows you to extend 0.50mm pitch 45 position FFC/FPC cables by 9". It consists of our QD7018-45C adapter board that allows two FFC/FPC parts to be connected together, along with our stock 45 position 0.50mm pitch 9" long FFC.

 0.50 45 9
800-00145

QD23207-12:  12" EXTENSION for 0.50mm 50 position
This kit allows you to extend 0.50mm pitch 50 position FFC/FPC cables by 12". It consists of our QD7018-50C adapter board that allows two FFC/FPC parts to be connected together, along with our stock 50 position 0.50mm pitch 12" long FFC.

 0.50 50 12
800-00146

QD23207-15:  15" EXTENSION for 0.50mm 50 position
This kit allows you to extend 0.50mm pitch 50 position FFC/FPC cables by 15". It consists of our QD7018-50C adapter board that allows two FFC/FPC parts to be connected together, along with our stock 50 position 0.50mm pitch 15" long FFC.

 0.50 50 15
800-00144

QD23207-9:  9" EXTENSION for 0.50mm 50 position
This kit allows you to extend 0.50mm pitch 50 position FFC/FPC cables by 9". It consists of our QD7018-50C adapter board that allows two FFC/FPC parts to be connected together, along with our stock 50 position 0.50mm pitch 9" long FFC.

 0.50 50 9
800-00143

QD23207-6:  6" EXTENSION for 0.50mm 50 position
This kit allows you to extend 0.50mm pitch 50 position FFC/FPC cables by 6". It consists of our QD7018-50C adapter board that allows two FFC/FPC parts to be connected together, along with our stock 50 position 0.50mm pitch 6" long FFC.

 0.50 50 6
800-00142

QD23207-3:  3" EXTENSION for 0.50mm 50 position
This kit allows you to extend 0.50mm pitch 50 position FFC/FPC cables by 3". It consists of our QD7018-50C adapter board that allows two FFC/FPC parts to be connected together, along with our stock 50 position 0.50mm pitch 3" long FFC.

 0.50 50 3
800-00141

QD23301-12:  12" EXTENSION for 1mm 6 position
This kit allows you to extend 1.0mm pitch 6 position FFC/FPC cables by 12". It consists of a discrete wire portion, and a short FFC. 6 position 1.0mm pitch FFC or FPC parts are inserted in one end.

 1.0 6 12
800-00140

QD23301-6:  6" EXTENSION for 1mm 6 position
This kit allows you to extend 1.0mm pitch 6 position FFC/FPC cables by 6". It consists of a discrete wire portion, and a short FFC. 6 position 1.0mm pitch FFC or FPC parts are inserted in one end.

 1.0 6 6
800-00139

QD23300-12:  12" EXTENSION for 1mm 4 position
This kit allows you to extend 1.0mm pitch 4 position FFC/FPC cables by 12". It consists of a discrete wire portion, and a short FFC. 4 position 1.0mm pitch FFC or FPC parts are inserted in one end.

 1.0 4 12
800-00138

QD23300-6:  6" EXTENSION for 1mm 4 position
This kit allows you to extend 1.0mm pitch 4 position FFC/FPC cables by 6". It consists of a discrete wire portion, and a short FFC. 4 position 1.0mm pitch FFC or FPC parts are inserted in one end.

 1.0 4 6
800-00137

QD23205-12:  12" EXTENSION for 0.50mm 40 position
This kit allows you to extend 0.50mm pitch 40 position FFC/FPC cables by 12". It consists of our QD7018-40C adapter board that allows two FFC/FPC parts to be connected together, along with our stock 40 position 0.50mm pitch 12" long FFC.

 0.50 40 12
800-00136

QD23205-6:  6" EXTENSION for 0.50mm 40 position
This kit allows you to extend 0.50mm pitch 40 position FFC/FPC cables by 6". It consists of our QD7018-40C adapter board that allows two FFC/FPC parts to be connected together, along with our stock 40 position 0.50mm pitch 6" long FFC.

 0.50 40 6
800-00135

QD23205-2:  2" EXTENSION for 0.50mm 40 position
This kit allows you to extend 0.50mm pitch 40 position FFC/FPC cables by 2". It consists of our QD7018-40C adapter board that allows two FFC/FPC parts to be connected together, along with our stock 40 position 0.50mm pitch 2" long FFC.

 0.50 40 2
800-00134

QD23204-12:    12" EXTENSION for 0.50mm 33 position
This kit allows you to extend 0.50mm pitch 33 position FFC/FPC cables by 12".  It consists of
our QD7018-33C adapter board that allows two FFC/FPC parts to be connected together, along with our stock 33 position 0.50mm pitch 12" long FFC.

 0.50 33 12
800-00133

QD23204-9:    9" EXTENSION for 0.50mm 33 position
This kit allows you to extend 0.50mm pitch 33 position FFC/FPC cables by 9".  It consists of our QD7018-33C adapter board that allows two FFC/FPC parts to be connected together, along with our stock 33 position 0.50mm pitch 9" long FFC.

 0.50 33 9
800-00132

QD23204-6:     6" EXTENSION for 0.50mm 33 position
This kit allows you to extend 0.50mm pitch 33 position FFC/FPC cables by 6".  It consists of our QD7018-33C adapter board that allows two FFC/FPC parts to be connected together, along with our stock 33 position 0.50mm pitch 6" long FFC.

 0.50 33 6
800-00131

QD23204-3:    3" EXTENSION for 0.50mm 33 position
This kit allows you to extend 0.50mm pitch 33 position FFC/FPC cables by 3".  It consists of
our QD7018-33C adapter board that allows two FFC/FPC parts to be connected together, along with our stock 33 position 0.50mm pitch 3" long FFC.

 0.50 33 3
400-00057

QD7018-30C:

This 0.50mm pitch ZIF adapter board allows two 30 conductor FFC/FPC's to connect to each other.

 0.50 30
CUSTOM

If you don't see what you need, feel free to contact the Quadrangle Products Sales/Engineering department.
sales@quadrangleproducts.com
engineering@quadrangleproducts.com
400-00032

QD7018-04C:

This 0.50mm pitch ZIF adapter board allows two 4 conductor FFC/FPC's to connect to each other.

 0.50 4
600-00022

QD9882: 6" EXTENSION for 0.30mm 51 position
0.30mm pitch 51 position 6.00" long FPC Extension Cable, can be used to extend 51 position FPC pigtail. QD9882 is RoHS compliant.

Also available in 1" length

 0.30 51 6
600-00020

QD9864FPC:
0.30mm pitch 45 position 6.00" long extension cable, can be used to extend 45 position FPC pigtail. QD9864 is RoHS compliant

 0.30 45 6
600-00010

QD6544FPC ADAPTER:
Can be used to convert from 0.3mm 45C FPC pigtail to discrete wire cable. QD6544 can be use with QD6023 discrete wire flying lead. QD6544 is RoHS compliant.

 0.30 45 2
400-00038

QD7018-50C:

This 0.50mm pitch ZIF adapter board allows two 50 conductor FFC/FPC's to connect to each other.

 0.50 50
400-00037

QD7018-45C:

This 0.50mm pitch ZIF adapter board allows two 45 conductor FFC/FPC's to connect to each other.

 0.50 45
400-00036

QD7018-40C:

This 0.50mm pitch ZIF adapter board allows two 40 conductor FFC/FPC's to connect to each other.

 0.50 40
400-00035

QD7018-33C:

This 0.50mm pitch ZIF adapter board allows two 33 conductor FFC/FPC's to connect to each other.

 0.50 33
400-00034

QD7018-20C:

This 0.50mm pitch ZIF adapter board allows two 20 conductor FFC/FPC's to connect to each other.

 0.50 20
400-00033

QD7018-10C:

This 0.50mm pitch ZIF adapter board allows two 10 conductor FFC/FPC's to connect to each other.

 0.50 10
